Day 10: Output Values & Local Values

Welcome to Day 10! Today we’ll explore two powerful features that make Terraform configurations more organized and reusable: output values for sharing data and local values for reducing repetition.

🎯 Today’s Goals

• Master output values and their uses

• Learn local values and when to use them

• Understand output dependencies

• Share data between root and child modules

• Organize complex expressions with locals

📤 Output Values Deep Dive

Output values expose information about your infrastructure after Terraform runs. Think of them as return values from your configuration.

Basic Output Syntax

output "output_name" {
  description = "Description of what this outputs"
  value       = expression
  sensitive   = false  # optional
  depends_on  = []     # optional
}

Why Use Outputs?

1. Display information to users after apply

2. Share data between configurations

3. Pass data to parent modules

4. Feed data to other tools (CI/CD, scripts)

5. Document infrastructure details

🎨 Output Value Examples

Simple Outputs

output "vpc_id" {
  description = "ID of the VPC"
  value       = aws_vpc.main.id
}

output "instance_public_ip" {
  description = "Public IP of the instance"
  value       = aws_instance.web.public_ip
}

output "region" {
  description = "AWS region"
  value       = var.aws_region
}

List Outputs

output "subnet_ids" {
  description = "IDs of all subnets"
  value       = aws_subnet.public[*].id
}

output "availability_zones" {
  description = "Availability zones used"
  value       = aws_subnet.public[*].availability_zone
}

# Output list of maps
output "subnet_details" {
  description = "Detailed subnet information"
  value = [
    for subnet in aws_subnet.public : {
      id   = subnet.id
      cidr = subnet.cidr_block
      az   = subnet.availability_zone
    }
  ]
}

Map Outputs

output "instance_ips" {
  description = "Map of instance names to IPs"
  value = {
    for name, instance in aws_instance.servers :
    name => instance.public_ip
  }
}

output "security_group_rules" {
  description = "Security group details"
  value = {
    for sg_name, sg in aws_security_group.groups :
    sg_name => {
      id          = sg.id
      name        = sg.name
      description = sg.description
    }
  }
}

Computed Outputs

output "website_url" {
  description = "Full URL to access the website"
  value       = "<https://$>{aws_instance.web.public_dns}"
}

output "connection_string" {
  description = "Database connection string"
  value       = "postgresql://${aws_db_instance.main.username}@${aws_db_instance.main.endpoint}/${aws_db_instance.main.db_name}"
}

output "total_subnet_count" {
  description = "Total number of subnets"
  value       = length(aws_subnet.public) + length(aws_subnet.private)
}

Sensitive Outputs

output "db_password" {
  description = "Database password"
  value       = aws_db_instance.main.password
  sensitive   = true  # Won't show in console output
}

output "api_key" {
  description = "API key for application"
  value       = random_password.api_key.result
  sensitive   = true
}

# View sensitive outputs
# terraform output -raw db_password

Conditional Outputs

output "nat_gateway_ip" {
  description = "NAT Gateway public IP"
  value       = var.create_nat_gateway ? aws_nat_gateway.main[0].public_ip : "Not created"
}

output "load_balancer_dns" {
  description = "Load balancer DNS name"
  value       = var.environment == "prod" ? aws_lb.main[0].dns_name : null
}

🔄 Output Dependencies

Sometimes an output needs to wait for other resources:

# Output depends on route table association being complete
output "vpc_ready" {
  description = "VPC is fully configured"
  value       = "VPC ${aws_vpc.main.id} is ready"

  depends_on = [
    aws_route_table_association.public,
    aws_internet_gateway.main
  ]
}

📍 Local Values

Local values assign names to expressions, making configurations more readable and reducing repetition.

Basic Local Syntax

locals {
  # Simple locals
  environment = "production"
  region      = "us-east-1"

  # Computed locals
  common_tags = {
    Environment = var.environment
    ManagedBy   = "Terraform"
    Project     = var.project_name
  }

  # String interpolation
  resource_prefix = "${var.project_name}-${var.environment}"

  # Conditional locals
  instance_type = var.environment == "prod" ? "t3.large" : "t2.micro"
}

# Reference with local.name
resource "aws_instance" "web" {
  instance_type = local.instance_type
  tags          = local.common_tags
}

When to Use Locals

✅ Use locals for:

1. Repeated expressions - DRY principle

2. Complex calculations - Improve readability

3. Conditional logic - Simplify resource blocks

4. Combining variables - Create derived values

5. Transforming data - Process variable inputs

❌ Don’t use locals for:

1. Simple variable references

2. One-time expressions

3. Values that should be variables

🎯 Locals vs Variables

🧪 Hands-On Lab: Outputs & Locals

Let’s build a complete infrastructure using outputs and locals effectively!

Step 1: Create Project Structure

mkdir terraform-outputs-locals
cd terraform-outputs-locals

Step 2: Create variables.tf

# variables.tf

variable "aws_region" {
  description = "AWS region"
  type        = string
  default     = "us-east-1"
}

variable "project_name" {
  description = "Project name"
  type        = string
  default     = "webapp"
}

variable "environment" {
  description = "Environment (dev, staging, prod)"
  type        = string

  validation {
    condition     = contains(["dev", "staging", "prod"], var.environment)
    error_message = "Must be dev, staging, or prod."
  }
}

variable "vpc_cidr" {
  description = "VPC CIDR block"
  type        = string
  default     = "10.0.0.0/16"
}

variable "availability_zones" {
  description = "Availability zones"
  type        = list(string)
  default     = ["us-east-1a", "us-east-1b"]
}

variable "create_nat_gateway" {
  description = "Create NAT gateway for private subnets"
  type        = bool
  default     = false
}

variable "enable_monitoring" {
  description = "Enable detailed monitoring"
  type        = bool
  default     = false
}

Step 3: Create locals.tf

# locals.tf

locals {
  # Naming convention
  resource_prefix = "${var.project_name}-${var.environment}"

  # Common tags
  common_tags = {
    Project     = var.project_name
    Environment = var.environment
    ManagedBy   = "Terraform"
    CreatedAt   = timestamp()
  }

  # Environment-specific configurations
  instance_type = {
    dev     = "t2.micro"
    staging = "t2.small"
    prod    = "t3.large"
  }

  instance_count = {
    dev     = 1
    staging = 2
    prod    = 3
  }

  # Network calculations
  public_subnet_cidrs = [
    for idx in range(length(var.availability_zones)) :
    cidrsubnet(var.vpc_cidr, 8, idx)
  ]

  private_subnet_cidrs = [
    for idx in range(length(var.availability_zones)) :
    cidrsubnet(var.vpc_cidr, 8, idx + 10)
  ]

  # Security group rules based on environment
  allowed_ssh_cidrs = var.environment == "prod" ? ["10.0.0.0/8"] : ["0.0.0.0/0"]

  # Conditional resource creation flags
  create_private_subnets = var.environment != "dev"
  enable_vpc_flow_logs   = var.environment == "prod"

  # Backup configuration
  backup_retention_days = {
    dev     = 7
    staging = 14
    prod    = 30
  }

  # Computed values
  all_subnet_cidrs = concat(local.public_subnet_cidrs, local.private_subnet_cidrs)
  total_subnets    = length(local.all_subnet_cidrs)

  # Feature flags
  features = {
    monitoring       = var.enable_monitoring
    nat_gateway      = var.create_nat_gateway
    private_subnets  = local.create_private_subnets
    flow_logs        = local.enable_vpc_flow_logs
  }
}

Step 4: Create main.tf

# main.tf

terraform {
  required_version = ">= 1.0"
  required_providers {
    aws = {
      source  = "hashicorp/aws"
      version = "~> 5.0"
    }
  }
}

provider "aws" {
  region = var.aws_region

  default_tags {
    tags = local.common_tags
  }
}

# VPC
resource "aws_vpc" "main" {
  cidr_block           = var.vpc_cidr
  enable_dns_hostnames = true
  enable_dns_support   = true

  tags = {
    Name = "${local.resource_prefix}-vpc"
  }
}

# Internet Gateway
resource "aws_internet_gateway" "main" {
  vpc_id = aws_vpc.main.id

  tags = {
    Name = "${local.resource_prefix}-igw"
  }
}

# Public Subnets
resource "aws_subnet" "public" {
  count = length(var.availability_zones)

  vpc_id                  = aws_vpc.main.id
  cidr_block              = local.public_subnet_cidrs[count.index]
  availability_zone       = var.availability_zones[count.index]
  map_public_ip_on_launch = true

  tags = {
    Name = "${local.resource_prefix}-public-${count.index + 1}"
    Type = "Public"
  }
}

# Private Subnets (only in staging and prod)
resource "aws_subnet" "private" {
  count = local.create_private_subnets ? length(var.availability_zones) : 0

  vpc_id            = aws_vpc.main.id
  cidr_block        = local.private_subnet_cidrs[count.index]
  availability_zone = var.availability_zones[count.index]

  tags = {
    Name = "${local.resource_prefix}-private-${count.index + 1}"
    Type = "Private"
  }
}

# Public Route Table
resource "aws_route_table" "public" {
  vpc_id = aws_vpc.main.id

  route {
    cidr_block = "0.0.0.0/0"
    gateway_id = aws_internet_gateway.main.id
  }

  tags = {
    Name = "${local.resource_prefix}-public-rt"
  }
}

# Route Table Associations
resource "aws_route_table_association" "public" {
  count = length(aws_subnet.public)

  subnet_id      = aws_subnet.public[count.index].id
  route_table_id = aws_route_table.public.id
}

# Security Group
resource "aws_security_group" "web" {
  name        = "${local.resource_prefix}-web-sg"
  description = "Security group for web servers"
  vpc_id      = aws_vpc.main.id

  ingress {
    description = "HTTP"
    from_port   = 80
    to_port     = 80
    protocol    = "tcp"
    cidr_blocks = ["0.0.0.0/0"]
  }

  ingress {
    description = "HTTPS"
    from_port   = 443
    to_port     = 443
    protocol    = "tcp"
    cidr_blocks = ["0.0.0.0/0"]
  }

  ingress {
    description = "SSH"
    from_port   = 22
    to_port     = 22
    protocol    = "tcp"
    cidr_blocks = local.allowed_ssh_cidrs
  }

  egress {
    from_port   = 0
    to_port     = 0
    protocol    = "-1"
    cidr_blocks = ["0.0.0.0/0"]
  }

  tags = {
    Name = "${local.resource_prefix}-web-sg"
  }
}

# Data source for latest AMI
data "aws_ami" "amazon_linux" {
  most_recent = true
  owners      = ["amazon"]

  filter {
    name   = "name"
    values = ["amzn2-ami-hvm-*-x86_64-gp2"]
  }
}

# EC2 Instances
resource "aws_instance" "web" {
  count = local.instance_count[var.environment]

  ami                    = data.aws_ami.amazon_linux.id
  instance_type          = local.instance_type[var.environment]
  subnet_id              = aws_subnet.public[count.index % length(aws_subnet.public)].id
  vpc_security_group_ids = [aws_security_group.web.id]
  monitoring             = var.enable_monitoring

  user_data = <<-EOF
              #!/bin/bash
              yum update -y
              yum install -y httpd
              systemctl start httpd
              systemctl enable httpd
              echo "<h1>Instance ${count.index + 1} in ${var.environment}</h1>" > /var/www/html/index.html
              echo "<p>Deployed by Terraform</p>" >> /var/www/html/index.html
              EOF

  tags = {
    Name  = "${local.resource_prefix}-web-${count.index + 1}"
    Tier  = "Web"
    Index = count.index + 1
  }
}

Step 5: Create outputs.tf

# outputs.tf

# VPC Outputs
output "vpc_id" {
  description = "ID of the VPC"
  value       = aws_vpc.main.id
}

output "vpc_cidr" {
  description = "CIDR block of the VPC"
  value       = aws_vpc.main.cidr_block
}

output "vpc_arn" {
  description = "ARN of the VPC"
  value       = aws_vpc.main.arn
}

# Network Outputs
output "public_subnet_ids" {
  description = "IDs of public subnets"
  value       = aws_subnet.public[*].id
}

output "private_subnet_ids" {
  description = "IDs of private subnets"
  value       = aws_subnet.private[*].id
}

output "all_subnet_ids" {
  description = "All subnet IDs"
  value       = concat(aws_subnet.public[*].id, aws_subnet.private[*].id)
}

# Instance Outputs
output "instance_ids" {
  description = "IDs of EC2 instances"
  value       = aws_instance.web[*].id
}

output "instance_public_ips" {
  description = "Public IPs of instances"
  value       = aws_instance.web[*].public_ip
}

output "instance_private_ips" {
  description = "Private IPs of instances"
  value       = aws_instance.web[*].private_ip
}

# Website URLs
output "website_urls" {
  description = "URLs to access instances"
  value = [
    for instance in aws_instance.web :
    "<http://$>{instance.public_ip}"
  ]
}

# Security Group Output
output "web_security_group_id" {
  description = "ID of web security group"
  value       = aws_security_group.web.id
}

# Environment Information
output "environment_config" {
  description = "Environment configuration summary"
  value = {
    environment    = var.environment
    region         = var.aws_region
    instance_type  = local.instance_type[var.environment]
    instance_count = local.instance_count[var.environment]
    features       = local.features
  }
}

# Computed Outputs
output "total_resources" {
  description = "Total count of resources created"
  value = {
    vpc               = 1
    subnets           = length(aws_subnet.public) + length(aws_subnet.private)
    instances         = length(aws_instance.web)
    security_groups   = 1
  }
}

# Infrastructure Summary
output "infrastructure_summary" {
  description = "Complete infrastructure summary"
  value = <<-EOT

    ========================================
    Infrastructure Deployment Summary
    ========================================
    Project: ${var.project_name}
    Environment: ${var.environment}
    Region: ${var.aws_region}

    VPC ID: ${aws_vpc.main.id}
    VPC CIDR: ${aws_vpc.main.cidr_block}

    Subnets:
    ${join("\\n", [for subnet in aws_subnet.public : "  - ${subnet.id} (${subnet.cidr_block})"])}

    Instances:
    ${join("\\n", [for idx, instance in aws_instance.web : "  - Instance ${idx + 1}: ${instance.public_ip}"])}

    Access URLs:
    ${join("\\n", [for instance in aws_instance.web : "  - <http://$>{instance.public_ip}"])}
    ========================================
  EOT
}

# Local Values Output (for debugging)
output "local_values" {
  description = "Local values for reference"
  value = {
    resource_prefix       = local.resource_prefix
    public_subnet_cidrs   = local.public_subnet_cidrs
    private_subnet_cidrs  = local.private_subnet_cidrs
    backup_retention_days = local.backup_retention_days[var.environment]
  }
}

Step 6: Create terraform.tfvars

# terraform.tfvars

aws_region         = "us-east-1"
project_name       = "myapp"
environment        = "dev"
vpc_cidr           = "10.0.0.0/16"
availability_zones = ["us-east-1a", "us-east-1b"]
create_nat_gateway = false
enable_monitoring  = false

Step 7: Deploy and Test

# Initialize
terraform init
# Plan
terraform plan
# Apply
terraform apply -auto-approve
# View all outpu
tsterraform output
# View specific output
terraform output vpc_id
# View formatted summary
terraform output infrastructure_summary
# Get raw value for scripting
PUBLIC_IP=$(terraform output -raw instance_public_ips | jq -r '.[0]')curl http://$PUBLIC_IP

Step 8: Test Different Environments

Create prod.tfvars:

environment        = "prod"
vpc_cidr           = "172.16.0.0/16"
create_nat_gateway = true
enable_monitoring  = true

terraform plan -var-file="prod.tfvars"

Notice how locals change the configuration based on the environment!

Step 9: Query Outputs Programmatically

# Get JSON output
terraform output -json > outputs.json
# Parse with jq
cat outputs.json | jq '.instance_public_ips.value'
# Use in scripts
terraform output -json | jq -r '.website_urls.value[]' | while read url; do  echo "Testing $url"  curl -I $urldone

Step 10: Clean Up

terraform destroy -auto-approve

📝 Best Practices

Outputs

✅ DO:

• Add descriptions to all outputs

• Mark sensitive data with sensitive = true

• Group related outputs logically

• Use outputs to share data between configurations

• Output useful debugging information

❌ DON’T:

• Output unnecessary information

• Forget to mark sensitive values

• Use outputs for internal-only values (use locals)

Locals

✅ DO:

• Use locals for repeated expressions

• Name locals clearly and descriptively

• Group related locals in locals blocks

• Use locals for complex calculations

• Document complex local expressions

❌ DON’T:

• Overuse locals for simple values

• Create overly complex local expressions

• Use locals when a variable is more appropriate

📝 Summary

Today you learned:

• ✅ Output values and their purposes

• ✅ Different output types (simple, lists, maps, computed)

• ✅ Sensitive outputs

• ✅ Output dependencies

• ✅ Local values and when to use them

• ✅ Locals vs variables

• ✅ Organizing complex configurations

🚀 Tomorrow’s Preview

Day 11: Working with Lists, Maps, and Sets

Tomorrow we’ll:

• Deep dive into collection manipulation

• Master for expressions

• Learn splat expressions

• Use collection functions

• Build dynamic configurations

---

← Day 9: Input Variables | Day 11: Lists, Maps & Sets →

---

Remember: Outputs share data, locals reduce repetition!
